Diamond Pro®

The Diamond Pro retaining wall system is a proven solution for tall walls, commercial developments, and other critical wall needs. This product provides a rough-hewn, multi-piece look with the installation speed of a single-piece system.

Features & Benefits

  • Rear lip locators easily establish a uniform wall batter
  • A matching cap completes the system
  • Multiple face styles available

Please refer to this page for information regarding Precautionary Statement & California’s Proposition 65.

Displaying product options available in your project location
