Commercial Retaining Walls
Diamond Pro® Pin System
Architects and engineers choose the Diamond Pro line of retaining wall systems to create flexible, cost-effective solutions for a broad range of large commercial, municipal and residential retaining wall projects. Contractors choose the Diamond Pro product line of wall systems due to their time-tested strength.
Diamond Pro® PS utilizes a pin system as a location device in installation.
Features & Benefits
- Pin system installation method
- Large cores for ease in handling
- Ease of installation with oversized pin aligning cores
- Pin cores allow for multiple batter options
- Builds walls in excess of 50 feet when combined with geosynthetic reinforcement
- One square foot of wall face per block
- Gravity walls can be built up to 4 feet high, including the buried course, with 7.1º batter
- Minimum outside radius, measured on the top course to the front of the units: 4 feet
- Minimum inside radius, measured on the base course to the front of the units: 6 feet
- Setback/System Batter: Near Vertical and 1”/7.1º; additional system batter can be created by alternating pin placement on each course of wall
Please refer to this page for information regarding Precautionary Statement & California’s Proposition 65.
Displaying product options available in your project location
Downloadable Resources
Select the resources you’re interested in accessing. You can either download or share with a custom link.
0 Files Selected
0 Bytes
Need something else? We’re here to help with more resources or any questions. Talk to an Expert
-
-
Diamond Pro PS – CAD Details7.67MB | .ZIP2.19MB | .DWG
-
Diamond Pro PS Typical Capping – PDF Detail107.40KB | .PDF
-
Diamond Pro PS Typical Base Preparation – PDF Detail226.91KB | .PDF
-
Diamond Pro PS Typical Base Step-up – PDF Detail166.01KB | .PDF
-
Diamond Pro PS Typical Reinforced Cross Section – PDF Detail163.54KB | .PDF
-
Diamond Pro PS Typical Gravity Cross Section – PDF Detail138.74KB | .PDF
-
Diamond Pro PS Typical Excavation Oversizing – PDF Detail140.76KB | .PDF
-
Diamond Pro PS Typical Fence Cross Section – PDF Detail145.52KB | .PDF
-
Diamond Pro PS Typical Fence Section with Sleev-It – PDF Detail145.89KB | .PDF
-
Diamond Pro PS Typical Guard Rail Section – PDF Detail145.72KB | .PDF
-
Diamond Pro PS Typical Terraced Wall Cross Section – PDF Detail219.69KB | .PDF
-
Diamond Pro PS Typical Terraced Wall Connection – PDF Detail338.91KB | .PDF
-
Diamond Pro PS Typical Cross Section with Sidewalk – PDF Detail175.54KB | .PDF
-
Diamond Pro PS Typical Cross Section with Crest Slope – PDF Detail153.37KB | .PDF
-
Diamond Pro PS Typical Drainage Swale Cross Section – PDF Detail152.89KB | .PDF
-
Diamond Pro PS Typical Shoreline Cross Section – PDF Detail235.61KB | .PDF
-
Diamond Pro PS Typical Groundwater Intrusion Cross Section – PDF Detail190.83KB | .PDF
-
Diamond Pro PS Typical Drain Pipe Through Wall Face – PDF Detail169.40KB | .PDF
-
Diamond Pro PS Typical Drain Pipe Through Toe Slope – PDF Detail223.87KB | .PDF
-
Diamond Pro PS Typical Cross Section with Parallel Utilities – PDF Detail153.09KB | .PDF
-
Diamond Pro PS Typical Utilities Below Wall – PDF Detail243.94KB | .PDF
-
Diamond Pro PS Typical Small Utilities Through Wall – PDF Detail190.14KB | .PDF
-
Diamond Pro PS Typical Large Utilities Through Wall – PDF Detail194.45KB | .PDF
-
Diamond Pro PS Typical Reinforcement Connection – PDF Detail126.13KB | .PDF
-
Diamond Pro PS Typical Alternate Drop Structure Behind Wall – PDF Detail106.58KB | .PDF
-
Diamond Pro PS Typical Wall Abutting Structure – PDF Detail207.38KB | .PDF
-
Diamond Pro PS Typical Drop Structure Behind Wall – PDF Detail215.17KB | .PDF
-
Diamond Pro PS Typical Outside Curves – PDF Detail153.13KB | .PDF
-
Diamond Pro PS Typical Inside Curves – PDF Detail114.48KB | .PDF
-
Diamond Pro PS Typical Outside Corners – PDF Detail340.12KB | .PDF
-
Diamond Pro PS Typical Inside Corners – PDF Detail384.51KB | .PDF
-
Diamond Pro PS Typical Outside Angles – PDF Detail117.40KB | .PDF
-
Diamond Pro PS Typical Inside Angles – PDF Detail123.39KB | .PDF
-
Diamond Pro PS Beveled Unit – PDF Detail114.39KB | .PDF
-
Diamond Pro PS Straight Unit – PDF Detail114.28KB | .PDF
-
Diamond Pro PS Stone Cut Unit – PDF Detail114.71KB | .PDF
-
Diamond Pro PS Virtual Joint Unit – PDF Detail115.36KB | .PDF
-
Diamond Pro PS Quarry Unit – PDF Detail111.40KB | .PDF
-
Diamond Pro PS Smooth Unit – PDF Detail110.35KB | .PDF
-
Diamond Pro PS Victorian Unit – PDF Detail114.43KB | .PDF
-
-
-
Diamond Pro PS Beveled Face – National Cut Sheet492.34KB | .PDF
-
Diamond Pro PS Quarried Face – National Cut Sheet382.09KB | .PDF
-
Diamond Pro PS Smooth Face – National Cut Sheet478.62KB | .PDF
-
Diamond Pro PS Straight Face – National Cut Sheet443.28KB | .PDF
-
Diamond Pro PS Victorian Face – National Cut Sheet438.21KB | .PDF
-
Diamond Pro PS Virtual Joint/Vintage Face – National Cut Sheet543.55KB | .PDF
-
-
-
SRW Quick Reference Install Guide541.01KB | .PDF
-
